REVOLVE2500

The 3rd size in the ROTATION Revolve range. Although compact in diameter, this unit can handle some serious payload - 1,800kg's !!



YouTube









Specifications of Revolve2500HD





• Diameter [mm]: 2559

• Height [mm]: 250

• Capacity [kg]: 3500

• Speed [rpm]: 1.0 to 2.0

• Accel/Decel [m/sec ²]: 1.0

• Control : Variable Speed Drive, Programmable Logic Controller, WiFi

• Finishes : Timber, carpet, vinyl, galvinised, aluminium, stainless steel, request

• Power Supply [Voltage/Amps]: 240-415/10

• Safety : Emergency stop button/s





Specifications of Revolve2500S



• Diameter [mm]: 2559

• Height [mm]: 250

• Capacity [kg]: 1500

• Speed [rpm]:1.0 to 2.0

• Accel/Decel [m/sec ²]: 1.0

• Control : Variable speed drive, programmable logic controller, wifi

• Finishes : Timber, carpet, vinyl, galvinised, aluminium, stainless steel, request

• Power Supply [Voltage/Amps]: 240-415/10

• Safety : Emergency stop button/s
